What it does: The Topology Optimization Density Point Map block creates a Scalar Point Map from a Topology Optimization that represents the TopOpt’s density result. Common uses:
  • Can visualize density results from Topology Optimization.
Tips:
  • The point map consists of all the nodal points from the Topology Optimization, and the density values associated with each of those points. These points and values are accessible in the properties of the Point Map.
  • The HUD can be used to change the Lower bound, Upper bound color palette and units as required.
  • The point map can be exported with the Export Point Map block.

​
Example File

Download Example: Topology Optimization Density Point Map Topology Optimization Density Point Map
Create a Scalar Point Map from the element densities resulting from a Topology Optimization.The centroid of each element defines the location of each point.

​
Inputs

NameTypeDescription
ResultTopology Optimization ResultThe topology optimization result to extract the element densities from.

​
Outputs

Type
Scalar Point Map
