Objective:

How to transition a blending gyroids workflow from the old to new latticing blocks.

​
Applies to:

  • Cylindrical Volume Lattice
  • Cylindrical Cell Map

​
Procedure:

1. Initialise the geometry. Add two Cylinder blocks that are of the same height and perform a Boolean Subtract. mceclip0.png 2. Creating a TPMS lattice in the old and new lattice pipelines.
Old Lattice BlocksNew Lattice Blocks with Volume LatticeNew Lattice Blocks
Walled TPMS CylinderCylindrical Volume LatticeTrim Lattice
Periodic Lattice
Faded_TPMS.png 3. The Ramp block is used to Fade in the gyroid. (How do I use the Ramp block?) mceclip1.png And that’s it! You’ve successfully applied and learned how to create a TPMS structure and blend it in with the new pipeline. Are you still having issues? Contact the support team, and we’ll be happy to help!

​
Download the Example file:

​
More on this topic:

​
Keywords:

lattice TPMS gyroid blend new periodic old
