About this course
This training walks you through how to create a two-channel heat exchanger with fields. While more complex than using the TPMS blocks, fields allow for more control of the heat exchanger design. Prerequisites: 101: nTop Essentials, 220: Intro to Field Driven Design, 321: Intermediate Field Driven Design, Intro to Two-Channel Heat Exchangers What is covered:- Understanding the difference between blocks and fields
- Creating a single channel heat exchanger with fields
- How to change the bias and wall thickness of a heat exchanger
- How to add baffles or caps to regions of the HEX Core
Helpful links
- Article: Designing the Optimal Heat Exchanger and White Paper
- Video Tutorial: CFD Driven Heat Exchanger Fin Orientation, Spacing and Sizing (~8 min)
- Video Tutorial: How to export your design to Ansys Fluent (~19 min)
- Video Tutorial: Advanced Heat Exchanger Design (~7 min)
- Video Tutorial: Preparing Fluid Volume Meshes for CFD Simulations (~11 min)
- Video Tutorial: Multiphysics Analysis of nTop Designs in Ansys (~16 min)
Advanced Two Channel Heat Exchanger through Field Manipulation
Create a two-channel heat exchanger with fields
